Winters Q324 Contractor Pressure Gauge 0-160 PSI

Winters Q324 Contractor Pressure Gauge 0-160 PSI Review

Winters Q324 Contractor Pressure Gauge 0-160 PSI Feature

• Winters Instruments
• Q324
• Water Gauges

Winters Q324 Contractor Pressure Gauge 0-160 PSIThe Winters Q324 Contractor Pressure Gauge 0-160 PSI is designed specifically for heating, ventilation, air conditioning and plumbing applications. This durable gauge is ideal for service on air, oil, water and steam and meets all ASME B40.1-1991 requirements. The instrument is also, CRN registered. The 4.5"(115mm) Contractor pressure gauge features a rugged stainless steel case and ring with a 1% full scale accuracy rating.* Dial face image will vary according to specificationsWinters Q324 Contractor Pressure Gauge 0-160 PSI Specifications:; Dial: 4-1/2" (115mm), white aluminum dial with black and red markings; Case: 304 stainless steel; Lens: Polycarbonate; Ring: 304 stainless steel; Pointer: Aluminum, anodized black, recalibrator screw; Socket: Brass; Connection: 1/4" NPT standard; Bourdon Tube: Phosphor bronze ; Movement: Brass ; Welding: Silver solder; Over-pressure Limit: 25% for pressures up to 1,400 psi (9,653 kPa)15% for pressures over 1,400 psi (9,653 kPa); Working Pressure: Maximum 75% of full scale value; Ambient / Process Temperature: -40F to 150F (-40C to +65C); Accuracy: +/-1% accuracy (ANSI/ASME Grade 1A)
